Building an Interpreter: Lexical Analysis - Part 3

• 5 min read
sparkles of colorful lightsPhoto by Shahadat Rahman

This post is part of a series called Building an Interpreter. After implementing a basic lexer and building more tokens, we'll extend the token set to work with special characters, new keywords, and the "equal" and "not equal" symbols.

Let's add support for ==, !, !=, -, /, *, <, >, and the keywords true, false, if, else, and return.

Single characters as tokens

First, the single characters, as they are the easiest ones to handle in the lexer.

We add this to the test:

const input = `
  !-/*5;
  5 < 10 > 5;
`;

Add new tokens:

export enum Tokens {
  // ...
  MINUS = '-',
  BANG = '!',
  ASTERISK = '*',
  SLASH = '/',
  LESS_THAN = '<',
  GREATER_THAN = '>',
  // ...
}

And finally, add the expectations in the test:

const tokens: Token[] = [
  // ...
  { type: Tokens.BANG, literal: '!' },
  { type: Tokens.MINUS, literal: '-' },
  { type: Tokens.SLASH, literal: '/' },
  { type: Tokens.ASTERISK, literal: '*' },
  { type: Tokens.INT, literal: '5' },
  { type: Tokens.SEMICOLON, literal: ';' },
  { type: Tokens.INT, literal: '5' },
  { type: Tokens.LESS_THAN, literal: '<' },
  { type: Tokens.INT, literal: '10' },
  { type: Tokens.GREATER_THAN, literal: '>' },
  { type: Tokens.INT, literal: '5' },
  { type: Tokens.SEMICOLON, literal: ';' },
  // ...
];

Now we just need to implement the lexer part to generate these token based on the source code:

private getToken(): Token {
  this.skipWhitespace();

  switch (this.char) {
    // ...
    case '!':
      return this.buildToken(Tokens.BANG, '!');
    case '-':
      return this.buildToken(Tokens.MINUS, '-');
    case '/':
      return this.buildToken(Tokens.SLASH, '/');
    case '*':
      return this.buildToken(Tokens.ASTERISK, '*');
    case '<':
      return this.buildToken(Tokens.LESS_THAN, '<');
    case '>':
      return this.buildToken(Tokens.GREATER_THAN, '>');
    // ...
  }
}

If we run the tests again, we make all green and passing.

Building new keywords as tokens

The process of building the tokens for the new keyword is pretty similar to the single characters.

Add the input to the test:

const input = `
  if (5 < 10) {
    return true;
  } else {
    return false;
  }
`;

Now add the expected tokens in the test:

const tokens: Token[] = [
  // ...
  { type: Tokens.IF, literal: 'if' },
  { type: Tokens.LPAREN, literal: '(' },
  { type: Tokens.INT, literal: '5' },
  { type: Tokens.LESS_THAN, literal: '<' },
  { type: Tokens.INT, literal: '10' },
  { type: Tokens.RPAREN, literal: ')' },
  { type: Tokens.LBRACE, literal: '{' },
  { type: Tokens.RETURN, literal: 'return' },
  { type: Tokens.TRUE, literal: 'true' },
  { type: Tokens.SEMICOLON, literal: ';' },
  { type: Tokens.RBRACE, literal: '}' },
  { type: Tokens.ELSE, literal: 'else' },
  { type: Tokens.LBRACE, literal: '{' },
  { type: Tokens.RETURN, literal: 'return' },
  { type: Tokens.FALSE, literal: 'false' },
  { type: Tokens.SEMICOLON, literal: ';' },
  { type: Tokens.RBRACE, literal: '}' },
  // ...
];

And the new tokens:

export enum Tokens {
  // ...
  TRUE = 'TRUE',
  FALSE = 'FALSE',
  IF = 'IF',
  ELSE = 'ELSE',
  RETURN = 'RETURN',
}

But the difference is that we also need to update the Keywords object to having the new tokens and be used in the lookupIdent function:

const Keywords: KeywordsType = {
  // ...
  true: Tokens.TRUE,
  false: Tokens.FALSE,
  if: Tokens.IF,
  else: Tokens.ELSE,
  return: Tokens.RETURN,
};

Running the tests again, we get all green and passing.

The Equal and Not Equal operators

What we want to do now is to build the Equal and Not Equal tokens. We start adding the source code we need to handle:

const input = `
  10 == 10;
  10 != 9;
`;

The expected tokens are:

const tokens: Token[] = [
  // ...
  { type: Tokens.INT, literal: '10' },
  { type: Tokens.EQUAL, literal: '==' },
  { type: Tokens.INT, literal: '10' },
  { type: Tokens.SEMICOLON, literal: ';' },
  { type: Tokens.INT, literal: '10' },
  { type: Tokens.NOT_EQUAL, literal: '!=' },
  { type: Tokens.INT, literal: '9' },
  { type: Tokens.SEMICOLON, literal: ';' },
  // ...
];

Then we need to add the new tokens:

export enum Tokens {
  // ...
  EQUAL = '==',
  NOT_EQUAL = '!=',
  // ...
}

Now we are ready to implement the lexer part for these new tokens.

First, the ==. Every time we get the character =, we need to be aware of if the next character is a = char. If it is, we return the token type Equal. If it's not, we just return the token type Assign.

To search for the next character, let's build a new method to handle that for us: peekChar.

private peekChar() {
  if (this.readPosition >= this.input.length) {
    return '';
  } else {
    return this.input[this.readPosition];
  }
}

It's a simple method: if we get to the end of the source code, we return an empty string. Otherwise, it returns the next character.

Now it becomes very easy to implement the lexer algorithm for the == token:

switch (this.char) {
  // ...
  case '=':
    if (this.peekChar() === '=') {
      this.readChar();
      return this.buildToken(Tokens.EQUAL, '==');
    } else {
      return this.buildToken(Tokens.ASSIGN, '=');
    }
  // ...
}

Inside the case of a = character, we see if the next character is also = with the help of our new method peekChar.

If it is, read the next character to update the position and the readPosition's states and return the new token type EQUAL.

If it is not, just return the already implemented token type ASSIGN.

We actually do this same implementation for the NOT_EQUAL token type:

switch (this.char) {
  // ...
  case '!':
    if (this.peekChar() === '=') {
      this.readChar();
      return this.buildToken(Tokens.NOT_EQUAL, '!=');
    } else {
      return this.buildToken(Tokens.BANG, '!');
    }
  // ...
}

But now we are looking at the ! character.

Final words & Resources

If you didn't have the opportunity, take a look at the first and the second part of the Lexical Analysis. This is the third post about my journey learning compilers and studying programming language theory. And part of the Building an Interpreter series.
